Why CertoClav EL sterilizer?
Compact: benchtop autoclave located directly at the laboratory workplace. Fast: short cycle times thanks to direct heating Practical: always processing the right quantity. No waiting for the big autoclaves Reliable: often more than 20 years in use. Lifelong service
|
|
{slider=Technical capability} - Power output: selectable between 125°/140°C. Special valve 115°/121°C available (0.7 - 2.7 bar / 10.2 - 39.2 psi overpressure). Solution of culture media (Agar) at 100°C
- Venting: venting using flow process. Steam saturation: non-condensable gases <3% (as mandated in EN 13060)
- Sterilisation material: solid instruments, liquids (culture media) bottles and devices, waste sterilisation
- Size, loading: optimal usage of chamber volume thanks to loading from above. Even long instruments up to 42 cm (18 L version) can be processed {/slider}
|
- Tried-and-tested technology: 50 years of experience in autoclave construction
Controller: pressure control via valve, temperature control via thermostat.
 |
Why CertoClav MultiControl sterilizer?
Flexible: Use in sterilisation, materials testing and research. Fractioned ventilation. Long-term cycles are easy to implement. Standard tests such as ICP-TM 650, GB-AL 631, HAST Test and Pressure Vessel Test can be carried out. Practical: automatic process control and monitoring saves valuable employee time Safe: independent error detection and data connection guarantee the sterilisation result. Reliable: control system and device in industrial quality
|
|
- Venting: Venting using fractioned flow process. Steam saturation: non-condensable gases 3% (as required by EN 13060)
- Autoclave items: solid instruments, liquids (culture media), bottles and devices, waste sterilisation. Any durable material for material tests and research. Acids can be autoclaved but do, however, lead to corrosion in the autoclave in the medium-term.
- Size, loading: optimal usage of chamber volume thanks to loading from above. Even long instruments up to 42 cm (18 L version) can be processed
- Multiple systems: The 4-stage CertoSecure safety system consists of an excess pressure valve, pressure valve, safety cover locking device against opening to pressure and overpressure safety recess.
- Safe operation: the CertoLock lock closes safely with just one easy step. No need for time-consuming screwing as with other makes.
Instruments: precision manometer with drag pointer, electronic temperature display. LCD display for process progress and process parameters. Data interface.
Connections: No additional water connection required. Electrics: 220V, 50-60Hz, 1900 W. Data interface RS 232 and 10mV
Standards: complies with international standards. GS mark in accordance with DIN and VDE/IEC (EN61010:1:2001 and 61010:2:040:2005). CE-conform.
Heater: integrated in base. Heating elements are not in contact with water, therefore extended service life.
|
|
|
|
|
- Power output: freely selectable temperature from room temperature up to 140° C (up to 2.7 bar / 39.2 psi overpressure).
